Virtual Design Construction (VDC)



TRIO’s engineering team also has VDC capabilities.

  • We use VDC coordination for design build projects and for value engineering
  • MEP collaboration including clash detection
  • As-built drawings before the work begins

Numerous benefits from the use of VDC Coordination:

  • Reduces errors in the field
  • Increases productivity and helps field hands with understanding of an area for installation
  • Cost cutting and reduces overhead cost

TRIO’s team uses the latest software for VDC:

  • 2016 AutoCAD MEP
  • 2016 AutoDesk Revit
  • 2016 AutoDesk Navisworks

1600 West Loop Building:

30th Floor Dist Feeders Real World

30th Floor Dist Feeders VDC

30th Floor Dist Feeders Real World





30th Floor Dist Feeders VDC

25th Floor Dist Feeders Real World

25th Floor Dist Feeders VDC

24th Floor Dist Feeders Real World

24th Floor Dist Feeders VDC

4th Floor Dist Feeders Real World

4th Floor Dist Feeders VDC

4th Floor Bustap Box Real World

4th Floor Bustap Box VDC
